Product Details:
|
| Name: | Zipper Shipping Boxes Machine | Power: | 18 KW (380V AC 3φ 50Hz) |
|---|---|---|---|
| Weight: | 1600kg | Machine Dimensions: | 6600*2100*1600 |
| The Highest Speed: | 60m/min | Material: | ≥300g/m²cartons |
| Warranty: | One Year | Color: | Polar Grey,Orange |
| Highlight: | Automatic Carton Box Gluing Machine,Carton Box Gluing Machine 1310mm,Automatic Carton Folding Gluing Machine |
||
Zipper shipping boxes Zipper shipping boxes machine
product description:
Full automatic stick double-sided adhesive machine is designed and researched by Deshisen CO., Ltd for single sheet water-based printing of corrugated container, Offset printing color-mounted corrugated cardboard boxes, cardboard color boxes, etc., affixed with double-sided tape and easy-to-tear tape simultaneously.
Any type of coding system can be set up on the platform for variable information printing, and a labeling head can be optionally installed. Local labeling function can be installed as well.
This series adopts a more optimized modular design, users can have more personalized choices, and achieve a multi-purpose design concept.
This equipment is widely used in pharmaceutical packaging, food packaging, logistics packaging, gift box packaging and other fields.
E-commerce special zipper carton third generation glue process
Compared with the first generation of double-sided glue, the second generation of foam glue two adhesive materials, the third generation of technology advantages are very obvious.
1, 10000 meters long endurance, production efficiency increased by 35%
2, hot melt adhesive material cost is 40% of double-sided adhesive
3, environmental protection degradation (double-sided adhesive can not be completely degraded)
Product parameters:
| Model | HM1300 | Working width | 1310mm |
| material | ≥300g/m²cartons | Air compressor | min. 6 bar |
| Minimum paper size | 250mm×250mm | total power | 18 KW (380V AC 3φ 50Hz) |
| Maximum paper size | 1300mm×1050mm | weight | 1600KG |
| The highest speed | 60m/min-100m/min | Machine dimensions | 6600*2100*1600 |
Feature:
1. The machine is running steady with strengthened driving system, and it is also easy for maintenance.
2. The motor is controlled by a transducer (inventer) which is available for automatic timing. It is power saved and helps to work stably.
3. An electric adjusting system in the machine makes it more conveniently when adjusting the space of carriers which usually based on the double-face tooth rods adjusting system.
4. Feeder is controlled by a separated motor. Paper is usually feed by several thick belts under the help of vibration motor. Feeding is continuous,exact and automatic with this system.
5. Grinders are provided in both sides of machine, to make gluing more stable and firm.
