Product Details:
|
| Printing Resolution: | 300 And 600dpi Horizontally And 200-900 Dpi Vertically | Nozzle Life: | 3 Years To 5 Years |
|---|---|---|---|
| Size Of The Drops: | Big, Medium And Small | Nozzle Width: | 54mm |
| Ink Type: | Oily Ink, UV LED Ink | Filtering Level: | Imported PALL10μm Filter, Through Two Filters, Protect The Nozzle. |
| High Light: | 200dpi Carton Box Inkjet Printer,350m/Min Carton Box Inkjet Printer,Inkjet Printer For Carton Box |
||
Carton Box Inkjet Printer / Maximum printing speed 200dpi -- 350 m/min / Nozzle width 54mm
1.Product catalog:
2. System technical parameters:
| number | The main content | Parameter | note |
| 1 | Printing resolution |
300 and 600dpi horizontally and 200-900 dpi vertically
|
The longitudinal direction is feeding direction |
| 2 | Nozzle width | 54mm | Ricoh G6 (Japan) |
| 3 | Spray printing height | 0.5mm--2mm within | |
| 4 | Nozzle life | 3 years to 5 years | |
| 5 | Size of the drops | Big, medium and small | Level 3 choice |
| 6 | Maximum printing speed |
200dpi -- 350 m/min 300dpi -- 220 m/min 400dpi -- 180 m/min 600dpi -- 120m/min |
Jet printing speed is related to the vertical resolution, the size of the ink drop point, and related to the platform feeding stability and material surface tension, the specific jet printing effect and speed should be based on the actual test results |
| 7 | Spray print content |
Support more than 40 one-dimensional bar CODE types (code-128A BC,UPC-AE,CODE39, etc.) support more than 10 kinds of two-dimensional CODE types (QRCODE, PDF417, DATAMATRIX, AZTEC, etc.) support graphic text functions (circle, triangle, numbers, characters, Chinese characters, curves, etc.).
|
|
| 8 | Printing database |
Support a variety of database formats (Access, Excel, TXT, SQL Server, Oracle, etc.), at the same time can be tuned into multiple databases, to achieve the same version of printing.
|
|
| 9 | Nozzle lifting mode | pneumatic | |
| 10 | Nozzle moving from side to side | The knob is fixed and the guide rail is moved manually | |
| 11 | Ink type | Oily ink, UV LED ink | Uv curing, LED curing |
| 12 | Spray print medium |
Gold and silver cards, paper, self-adhesive, metal foil, UV white ink, OPP and other films.
|
Material must reach a certain dyne value, the specific test results prevail. |
| 13 | sprinkler |
Independently designed sprinkler protection device, convenient and flexible, completely isolated from the outside world.
|
|
| 14 | Ink way |
Centralized ink supply, separate negative pressure control nozzle.
|
|
| 15 | Filtering level |
Imported PALL10μm filter, through two filters, protect the nozzle.
|
|
| 16 | The secondary ink station |
Stable negative pressure, reduce ink leakage, make printing effect more stable.
|
|
| 17 | The work environment |
15-30℃, humidity 50%-75%, dustproof space.
|
|
| 18 | 1L ink printing code quantity |
Such as: 13*13mm two-dimensional code, 300*600DPI, about 1.1-1.2 million printing code.
|
|
3. Digital Inkjet Printing VS The Traditional Flexo Printing Work Flow Comparison:
1) The advantage of inkjet printing:
2. High technology
3 .High profits
4. Save Labor
5. Simple operation
6. Save time and energy
7. Intelligent management
2) The disadvantage of the flexo printing
2. Old mode
3. Benefit deficit
4. High labor cost
5. Various processes
6. Waste time
7. Complex management
